X1B Drone Detection Equipment
Description
Description
Product Introduction
Based on the TDOA spectrum detection technology, a single device can independently discover, early warn, identify and locate the uav (some common models). The networking of multiple devices can realize the real-time accurate positioning of multiple brands and multi-models, as well as self-made machines and crossing machines.
The device covers a wide frequency band, a long detection distance and strong anti-interference ability. With integrated industrial design and convenient deployment, it is suitable for low-altitude security operations in complex environments.
The features of the fixed UAV detection equipment system are as follows:
- Single station positioning: a single equipment can realize the positioning of some common models of UAV and pilots, and the unique serial number identification of UAV.
- Multi-station networking positioning: Multi-station networking based on TDOA technology can achieve multi-brand model positioning, with a positioning accuracy of 10m.
- All identification models: it can identify common models such as DJI and Daotong, as well as 800 + kinds of models such as self-made machines and crossing machines.
- Black and white list: effectively distinguish between cooperative and non-cooperative drones.
- Low false alarm rate: the average false alarm rate is <1 time / day.
- Active detection: passive detection, no active transmission of electromagnetic signals, environment friendly, high concealment.
- Strong anti-interference ability: stable operation in a complex urban environment.
- Integrated design: beautiful and easy, convenient installation and easy to use.
The main technical parameters are shown in the following table:
Table 2 Technical parameters of fixed UAV detection equipment
| Project | Parameter |
| Work pattern | Radio detection, and TDOA |
| The object of action | UAV map transmission, flight control link |
| Work frequency band | 100MHz~6GHz |
| Detection radius | The Urban environment is 2- -6 km
(There will be some differences according to the environment and model type) |
| Detect the quantity | ≥20 sorties (simultaneously) |
| Working temperature | -40℃~65℃ |
| Size | Diameter: 260mm ± 2mm height: 637mm ± 2mm |
| Levels of protection | IP66 |
Fixed uav detection equipment can detect to identify various types of drone target: can detect Xinjiang, tong, son, fly m, corbett, YunZhuo, dahua, the Skydio brand drones and other homemade FPV, WiFi drone nearly hundred types of drones, most of the drones, using the number of drones, using the simulation map of drones, and part of the homemade drones. The system has the ability to upgrade online, and continuously improve the identification type and number of non-cooperative targets.
