Handheld Drone Direction Finding Detector
The GNSS spoofer represents a significant advancement in UAV countermeasure technology, offering a fixed-site solution for enhancing low-altitude security defense. Despite its fixed installation, the device remains highly versatile and adaptable, allowing for easy deployment and flexible disassembly when needed. This feature ensures seamless integration into various security infrastructures, providing users with a reliable and efficient solution for protecting critical assets and infrastructure in low-altitude environments.
Key Benefits
Area Denial
Directional Diversion
24/7 Surveillance
Full Coverage
Description
Description
Portable drone detector specification:
Handheld drone direction finding detector is used for UAV direction detection, recognition and early warning. The device receives uav signals and realizes the detection and recognition of suspicious sources based on spectrum sensing and deep learning technology. When it detects a drone, the equipment can alarm through sound and light mode, prompting the on duty men to respond quickly and act promptly.
What’s more, the handheld drone detector can expand the direction finding function of the UAV. After replacing the full direction antenna with the direction finding antenna, the general direction of the target can be detected. It is suitable for uav prevention and control operations in major event security tasks, park inspection and other scenarios.
Handheld drone detector features are as follows:
- Light and durable: small volume, light weight, carry, earthquake anti-fall.
- All identification models: can identify DJI, Daotong, Hubson, Haoxiang and other common models, as well as self-made FPV, WiFi drones and other models.
- Direction models: DJI (Spirit series, Royal series), Daotong and Hubson and other drone models.
- Passive detection: do not actively transmit electromagnetic signals, environmentally friendly, high concealment.
- Low false alarm rate: the average false alarm rate is <1 time / day.
- Direction finding: optional direction finding antenna to expand the direction finding function.
- Strong endurance: built-in high-quality battery, sustainable work for more than 6 hours.
- Detection distance: the maximum detection distance can reach 1-2 km.
- Modular design: can be used independently, or can cooperate with the counter-gun operation.
- Real-time screen display: real-time display of detection status, quantity, and drone identity information.
Handheld UAV detection and finding detector parameter:
| Project | Parameter |
| Work Pattern | radio detecting and ranging |
| Work Frequency Band | Omni-directional mode: 900MHz, 1.1GHz, 1.2GHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz
Direction-finding mode: 2.4GHz, 5.8GHz |
| Detection Range | Omni-directional mode: 0.7km-1.2km
Direction finding mode: 1km-2km (There will be some differences according to the environment and model) |
| The Alarm Way | Light, sound |
| Direction Expansion | A direction-finding antenna is optional |
| Direction Measurement Accuracy | Azimuth error is <17.5° (at 1 km) |
| Working Temperature | -20℃~55℃ |
| Levels of Protection | IP54 |
| Equipment Size | Detection equipment: (L * W * H) 235mm * 66mm * 43mm
DF antenna: (L * W) 300mm * 217mm |
| Weight of Equipment | 800 g of detection equipment; 310 g of DF antenna |
