Handheld Detection and Navigation Spoofing Device
Description
Description
### Functional Features
-
**Signal Coverage and Detection**
– **Full-band coverage**: Covers the full frequency band of 600MHz – 6GHz, supporting FPV and mainstream consumer drone detection. It can comprehensively monitor drone signals in this frequency band and not miss any potential threats in any band.
– **Long-distance detection**: The detection distance for mainstream consumer models is ≥1.2km, and for FPV analog video transmission, it is ≥1.5km, enabling early long-distance drone discovery and gaining response time.
-
**Navigation Spoofing**
– **Multi-frequency navigation spoofing**: Standard with GPS L1/GLONASS G1 frequency bands, and can be customized with BDS B1, GALILEO E1, etc. The interference distance is ≥1km. It misleads drones to deviate from their targets by transmitting false navigation signals.
– **Precise coordinate deception**: Directly modifies the satellite navigation information received by the drone to make it achieve countermeasures and change the flight coordinates.
-
**Warning and Dispel**
– **Dual-mode warning system**: Equipped with a sound + vibration dual alarm mechanism, maintaining a low false alarm rate in complex electromagnetic environments and timely alerting operators.
– **Intelligent dispel strategy**: With dual modes of linear displacement and circular circling, it can tamper with the drone’s coordinates within 3 seconds to quickly achieve dispel control.
-
**Other Advantages**
– **Sub-second signal intrusion**: The whole process from detection to completion of navigation signal deception is as fast as less than 3 seconds, with rapid response.
– **Ultra-light portable design**: The whole machine is only 710g (excluding the antenna), small in size, and can be flexibly deployed with one-hand grip.
– **High-definition interactive interface**: A 2.4-inch LCD screen displays the working status in real time, with convenient and efficient operation.
– **Quick battery replacement support**: The battery is detachable and replaceable to ensure continuous protection capability for high-intensity tasks.
– **Excellent environmental adaptability**: The working temperature range is -20℃ – 55℃, adapting to extreme climates and complex electromagnetic scenarios.
– **Long-lasting battery life configuration**: The 3.5Ah battery supports 4 hours of continuous operation in detection mode, and the low-power design extends working time.
Detection Unit Specifications
| Parameter | Details |
| Frequency band | 600MHz–6GHz |
| Detection modes | Digital video transmission / analog video transmission |
| Detected models | Digital: Common consumer drones Analog: 600MHz–6GHz analog models |
| Detection range | Digital ≥1.2km* Analog ≥1.5km* |
Spoofing Unit Specifications
| Parameter | Details |
| Working mode | Navigation Spoofing |
| Supported bands | Standard: GPS L1, GLONASS G1 Customizable: BDS B1, GALILEO E1 |
| Transmission power | 10mW |
| Spoofing range | ≥1km* |
| Strategies | Linear displacement, circular circling |
| Signal intrusion | <3s |
Overall System Specifications
| Parameter | Details |
| Power consumption | ≤15W |
| Power supply | Rechargeable battery (support hot-swapping) |
| Battery capacity | 3S1P 12.6V 3.5Ah |
| Standby time | ≥4h |
| Operating temp. | -20℃–+55℃ |
| Weight | 710g (±5g) |
| Dimensions | 223×77×42±2mm (excluding antenna) |
