5 Km+ Turntable Long Range Navigation Spoofing GPS Glonass UAV Jammer
The product can actively regenerate deceptive signals in no less than two frequency bands of satellite navigation, providing deceptive interference to the navigation coordinate information received by UAVs using satellite navigation. It achieves directional diversion (8 directions), area denial and precision capture (expansion required)of UAVs functions. Additionally, the directional antenna on the turntable can enable the emission of navigation deception signals over longer distances, further enhancing the overall defense efficiency of lo-altitude security.
Long-term Reliable Defense Performance
The Navigation Spoofing Device is not just an intelligent and efficient unmanned aerial vehicle (UAV) intrusion defense tool, it is a comprehensive and reliable solution for users. Its robust features, user-friendly design, and versatile application scenarios make it an indispensable security tool in the face of current UAV threats. The efficient UAV countermeasure capability will provide users with long-term reliable defense performance, ensuring optimal satisfaction of your low-altitude security needs.
Key Benefits
√ Area Denial
√ Directional Diversion
√ Adjustable Power
√ Full Coverage
Description
Description
5 Km+ Turntable Gnss Spoofer
Long Range Navigation Spoofing GPS Glonass UAV Jammer
Technical Specifications
| Supported Frequency Bands | GPS L1, GLONASS L1 (expandable) |
| Signal Transmission Power | ≤ 5 W (expandable) |
| Operating Range | ≥ 5000 m (expandable) |
| Number of Simultaneously Spoofing UAVs by GNSS | ≥ 30 sorties |
| Rotation Angles | Horizontal 0°~ 360°/s Continuous rotation; Pitch -10°~ 90° |
| Signal Activation Time | < 3 s |
| Signal Intrusion Time | < 10 s |
| Power Consumption | ≤ 75 W |
| Operating Temperature | -40ºC to 70ºC |
| Weight | < 20 kg |
| Product Dimensions | 388 mm × 406 mm × 638 mm (L × W × H) |
*The data in the product specifications on this page may be subject to change. Please contact your dedicated account manager for the latest product details.
R-Shield-606A Performance Analysis
– Active Navigation Spoofing
The drone spoofer device is equipped with active navigation spoofing capabilities, able to actively regenerate deceptive signals in no less than two frequency bands of satellite navigation in real-time. This proactive countermeasure prevents unmanned aerial vehicles (UAVs) from operating normally when subjected to deceptive navigation coordinate information, effectively restricting their actions.
– Multifunctional Defense
In addition to deceiving navigation coordinate information, the device also implements multifunctional defense measures such as directional diversion (8 directions), area denial, and precision capture. Directional diversion guides unmanned aerial vehicles (UAVs) away from critical areas, area denial prevents UAVs from entering specified zones, and precision capture, when coordinated with other UAV defense devices, can selectively capture target UAVs, providing multi-layered security protection.
– Versatile Application Scenarios
This UAV spoofing device is suitable for various environments and scenarios, including but not limited to defense bases, government facilities, energy strongholds, large-scale event venues, etc. Users can deploy it in different locations as needed, providing comprehensive defense against unmanned aerial vehicle (UAV) intrusions.
– Sustainable Upgradability
With the continuous advancement of unmanned aerial vehicle (UAV) technology, this product supports sustainable upgradability to adapt to emerging threats and technological challenges. Users can ensure that the device maintains state-of-the-art low-altitude defense performance in the ever-changing threat landscape through straightforward software updates.
– Adaptability to Working Environments
The UAV spoofer has a wide operating temperature range from minus 40 degrees Celsius to 70 degrees Celsius, this device is suitable for various harsh climatic conditions. Simultaneously, with an IP66 protection rating, and it offers excellent dust and waterproof performance, ensuring reliable operation in diverse and complex environments.
– Powerful Effective Range
The anti-drone device has an effective range exceeding 500 meters, ensuring effective interference with unmanned aerial vehicles (UAVs) at relatively long distances. This extensive effective range allows users to safeguard the security of critical areas over a large area. Additionally, we offer customization, allowing the effective range of the device to be upgraded according to your specific requirements.
– Efficient Signal Activation and Intrusion Time
The anti-drone device has a rapid signal activation time (<3 seconds) and intrusion time (<10 seconds), the device can swiftly respond to the presence of unmanned aerial vehicles (UAVs), ensuring a timely response to potential threats.
– Highly Expandable Frequency Band Support
In addition to supporting major frequency bands such as GPS L1 and GLONASS L1, this device also features expandable frequency band support, making it more adaptable to various satellite navigation system frequencies. Therefore,this ensures that your low-altitude defense requirements can be personalized and meet.
– Round-the-Clock Surveillance
The drone spoofing device’s round-the-clock surveillance feature ensures uninterrupted operation day and night, providing users with continuous monitoring and defense against unmanned aerial vehicle (UAV) intrusions. This reliable 24/7 operational performance makes it an ideal choice for scenarios with high demands for real-time security.
Applications
Security & Counter-terrorism in the Oil & Petrochemical Industry
Security & Counter-terrorism in the Power Industry
Government & Security Agency
Civil Aviation Airport & Logistics Base
Large-Scale Event & Sport Competition
Urban No-Fly Zone Airspace Security
Business & Personal Privacy Protection
